Model |
KZ-250 |
KZ-320 |
KZ-350 |
|
Film width |
250mm |
320mm |
350mm |
|
Bag length |
45～ 280mm |
120-280mm |
150-330mm |
|
Bag width |
30 ～ 110mm |
50 ～ 160mm |
50 ～ 160mm |
|
Packaging speed |
40 ～ 300 bags/min |
40 ～ 300 bags/min |
40 ～ 300 bags/min |
|
Power supply |
220V,50/60HZ,2.4Kw |
220V,50/60HZ,2.4Kw |
220V,50/60HZ,2.4Kw |
|
Dimension (mm) |
(L)3770×(W)670×(H)1450mm |
(L)3770×(W)670×(H)1450mm |
(L)3770×(W)670×(H)1450mm |
|
Weight |
800Kg |
800Kg |
800Kg |
|
Model |
KZ-600 |
KZ-680 |
|
Film width |
600mm |
680mm |
|
Bag length |
120 ～ 450mm |
120-450mm |
|
Bag width |
50 ～ 200mm |
50 ～ 260mm |
|
Packaging speed |
40 ～ 150 bags/min |
40 ～ 100 bags/min |
|
Power supply |
220V,50/60HZ,2.4Kw |
220V,50/60HZ,2.4Kw |
|
Dimension (mm) |
(L)3770×(W)670×(H)1450mm |
(L)3770×(W)670×(H)1450mm |
|
Weight |
800Kg |
800Kg |
-
Take the film (suitable for rigid block product packaging ) -
Down film (suitable for soft block product packaging ) -
Automatic feed production line series (applies to product automatic finishing ,high speed , high precision automatic unmanned packaging -
Full automatic pillow packaging production line diagram -
Full automatic battled packaging production line -
-
-
2): Venting device
3): Gusset device
4): Hook the hole cutter seat
5): Date Printer
